New Arduino Sensor Starter Kit (UNO R3+Shield V5) with 30 Arduino Sensor Project/Tutorial

Regular price $53.00

Shipping calculated at checkout.

Introduction

This is an Arduino sensor learning kit developed by Keyes. We bring together 30 basic sensors and modules, aiming for the convenience of its learning for starters. Inside this box, there are digital and analog sensors and also some special modules such as buzzer, ultrasonic, acceleration modules etc. For each module, there is clear connection diagram and sample code. So even if you are totally new at this, you can get started easily.
The sample codes for this sensor kit are based on ARDUINO because it's open source and easy. And if you are good at this, you can also apply this kit to other MCU development platform, such as 51, STM32, Raspberries Pi. The working principle is pretty much the same.
Now, let us embrace this fascinating world of ARDUINO and learn together!

ks0083-1

ks0083-7ks0083-5ks0083-9

Shipping List

  • Keyestudio UNO control board *1
  • V5 sensor shield *1
  • Female to female Dupont line *40
  • usb cable *1
  • Piranha LED Module *1
  • Digital white LED module *1
  • Passive Buzzer module *1
  • Hall Magnetic Sensor *1
  • LM35 Temperature Sensor *1
  • 18B20 Temperature Sensor *1
  • Digital Tilt Sensor *1
  • Photocell sensor *1
  • Digital Push Button *1
  • Capacitive Touch Sensor *1
  • DHT11 Temperature and Humidity Sensor *1
  • Analog Sound Sensor *1
  • Flame Sensor *1
  • 3231 Clock Module *1
  • MQ-2 Analog Gas Sensor *1
  • MQ-3 Analog Alcohol Sensor *1
  • Water sensor *1
  • Soil humidity sensor *1
  • Infrared Obstacle Avoidance Sensor *1
  • PIR Motion Sensor *1
  • Joystick Module *1
  • photo interrupter module *1
  • 5V Relay Module *1
  • ADXL345 Three Axis Acceleration Module *1
  • Rotary Encoder module *1
  • Analog Rotation Sensor *1
  • HC-SR04 Ultrasonic Sensor *1
  • Pulse Rate Monitor *1
  • Reed Switch Module *1
  • TEMT6000 ambient light sensor *1

Project List

1. Piranha LED Module
2. Digital white LED module
3. Passive Buzzer module
4. Hall Magnetic Sensor
5. LM35 Temperature Sensor
6. 18B20 Temperature Sensor
7. Digital Tilt Sensor
8. Photocell sensor
9. Digital Push Button
10. Capacitive Touch Sensor
11. DHT11 Temperature and Humidity Sensor
12. Analog Sound Sensor
13. Flame Sensor
14. 3231 Clock Module
15. MQ-2 Analog Gas Sensor
16. MQ-3 Analog Alcohol Sensor
17. Water sensor
18. Soil humidity sensor
19. Infrared Obstacle Avoidance Sensor
20. PIR Motion Sensor
21. Joystick Module
22. photo interrupter module
23. 5V Relay Module
24. ADXL345 Three Axis Acceleration Module
25. Rotary Encoder module
26. Analog Rotation Sensor
27. HC-SR04 Ultrasonic Sensor
28. Pulse Rate Monitor
29. Reed Switch Module
30. TEMT6000 ambient light sensor

Packaging & Delivery

  • Selling Units:Single item
  • Single package size: 20X10X8 cm
  • Single gross weight:0.700 kg

For more details:

http://wiki.keyestudio.com/index.php/Ks0083_keyestudio_New_sensor_kit_with_Uno

PDF

https://drive.google.com/open?id=1lWfhvOlAPxtvyMkZk3_0HOnuueMl0Kcc
