L293D DC MOTOR DRIVER SMART HOME STEAM KIT FOR ARDUINO

Sale price $19.60 Regular price $21.67

Shipping calculated at checkout.

Introduction

  • Adopts L293D chip,it can drive 4 DC motors.
  • 4 Channel Stepper motor port.
  • Max Current:1 A.
  • Driver: L293D Dual H Bridge DC Motor Driver IC.
  • Driven part of the input voltage Vs: +5 ~ 16V (or +7-35V depending on power supply needs).
  • The logical part of the work current is: 0 – 36mA.
  • Drive part of the operating current Io: 2A.
  • Maximum power dissipation: 20W (T = 75 degree Celsius).
  • Control signal input level(IN1 IN2 IN3 IN4 IN5 IN6 IN7 IN8).
  • High level: 2.3V ≤ Vin ≤ Vss.
  • Low:-0.3V ≤ Vin ≤ 1.5V.
  • Operating temperature: -25 C ~ +130 C.
  • Drive Type: Dual high-power H-bridge driver.

Shipping List

  • L293D Duel-H Bridge 4WD 4 DC Stepper motor driver shield module for Smart Car x1
