Piano TTP229-LS shield Expansion Board For Micro bit

Regular price $9.99

Shipping calculated at checkout.

Introduction

This piano shield is fully compatible with the micro:bit development board.

The piano shield for micro:bit integrates the TTP229-LSF chip, 8 touch piano keys, 4 WS2812 LEDS and a passive buzzer element.

It also comes with 6 edge connectors, containing two 3V power input/output connectors, 2 signal connectors. So it provides an easy way to connect other sensors/modules to micro:bit main board.

Besides, it extends 2 rows of header pad interfaces, easy for soldering the pin headers/female headers of 2.54mm pitch. One row contains 3V power input/output and SPI communication; the other contains 3V power input/output, signal pin and I2C communication.

The shield has two 3.2mm fixed holes, convenient for mounting on other devices.

Piano TTP229-LS shield Expansion Board Music Development Board With WS2812 RGB Colored Light Buzzer For Micro bit

Specification

Power supply from:

  • Micro:bit main board: Micro USB port (5V); external power jack 3.3V
  • Piano shield: edge connectors (3V); header pad interface (3V)
  • Control chip: TTP229-LSF
  • Dimensions: 124mm*55mm*10mm
  • Weight: 29.9g

Hookup Guide

Insert firmly the micro:bit main board into the piano shield.


Source Code

Copy the hex file code to your micro:bit just like copying a file to a USB drive. You can right click and choose "Send To→MICROBIT"

thumb

Result

Send the code to micro:bit, the 4 WS2812 LEDS on the piano shield turn on red for 1 second, green for 1 second, blue for 1 second.

thumbthumbthumb

When touch the different piano keys, buzzer will make a tone, and the 4 WS2812 LEDS show shiny colors.
