Solar Energy Wind Belt Charging Constant Current Constant Voltage Power Supply Module LM2596 2577

Regular price $6.98

Shipping calculated at checkout.

Introduction

Input Voltage: 4-35V

Output Voltage: 1.25-25V continuously adjustable (default delivery voltage 4.2V current 1A, need other voltage can be adjusted)

Adjustment Method: the first input power (4-35V) and then use a multimeter to monitor the output voltage and adjust the potentiometer (generally turn up the pressure in turn, reverse the buck)

Output Current: 12V to 5V maximum 2A (output other voltage, calculated by 15W current, formula 15 / output voltage = output current)

Output Power: maximum 15W (such as high temperature please strengthen the heat)

Conversion Efficiency: 80% (the higher the output voltage, the higher the efficiency)

Operating Temperature: industrial (-40 ℃ to +85 ℃ ambient temperature of more than 40 degrees, please reduce the power to use, or strengthen the heat)

Full Load Temperature Rise: 45 ℃

Module Size: 50 * 37 * 13 (L*W*H)(mm)
