5 Pcs Smart Electronics 3pin Small BETR Mini Magnetic Dry Reed Pipe Switch Sensor Module

Regular price $6.20

Shipping calculated at checkout.

Introduction

PBX, photocopiers, washing machines, refrigerators, cameras, Disinfection cabinet, door, window magnetic, electromagnetic relay, electronic weighing, level meter, gas meter, water meter and so on have been a very good application.

1, imported normally open reed switch
2, the comparator output, the signal is clean, the waveform, driving ability, more than 15mA.
3, operating voltage 3.3V-5V
4, the output in the form: Digital switching outputs (0 and 1)
5, a fixed bolt hole for easy installation
6 small board PCB size: 3.2cm x 1.4cm
7, wide voltage LM393 comparator
Reed switch is an abbreviation of the dry reed contacts a passive electronic switching elements, and has the advantages of simple structure, small size and ease of control, its shell is a sealed glass tube, the tubes are installed two iron elastic reed plate, but also filling called rhodium metal inert gas. In peacetime, the glass tube in the two reeds is made of special materials are separated. When a magnetic substance close to the glass tube, in the role of the magnetic field lines, the pipe within the two reeds are magnetized to attract each other in contact, the reed will suck together, so that the junction point of the connected circuit communication. After the disappearance of the outer magnetic reed because of their flexibility and separate, the line is disconnected. Therefore, as a use of the magnetic field signals to control the line switching device, reed tube can be used as a sensor for counting the number, spacing, etc. (in the security system is mainly used for production of Menci, magnetic window), and also are widely used in a variety of communication devices.
